Lotrak Base Woven Geotextile

Test Standard 80 100 200 300
Tensile Strength(kN / m) EN 10319 MD 6 8 18 25
CD 6 8 18 25
Elongation at max. load(%) EN 10319 MD 36 45 50 65
CD 42 45 50 65
CBR Puncture Resistance (N) EN ISO 12236 1050 1500 2900 4300
Cone Drop Penetration (mm) EN 13433 48 36 18 13
Pore Size 90% finer than (microns) EN ISO 12956 128 100 70 70
Water Permeability(m / sec) EN ISO 11058 144×10-3 130×10-3 80×10-3 65×10-3
Effect of UV Light The Polypropylene used contains a UV inhibitor
Weight (g/m2) 80 100 200 300
Roll Size Width 4.5 4.5 4.5 4.5
Length 100 100 100 50/100
